FOP FOP

Selection guide | Fiber optic plates (FOP)

Fiber diameter(μm)
φ 3 φ 6
(large end)
φ 6 φ 25



J5743

J3182-74

J11057-74



J12221-74



Outer
Dimension(mm)

φ 12.5 - φ 25.0
Thickness(mm)
25.0

Outer
Dimension(mm)

φ 26.5
Thickness(mm)
3.0



Outer
Dimension(mm)

φ 26.5
Thickness(mm)
3.0



J5734



J3182-72

J11057-72

J3182-73

J11057-73

J11057-75

J11181-75

J12221-72

J12221-73

Outer
Dimension(mm)

13.59 × 6.86
Thickness(mm)
2.54



Outer
Dimension(mm)

30.0 x 20.0
Thickness(mm)
3.0

Outer
Dimension(mm)

50.0 x 50.0
Thickness(mm)
3.0

Outer
Dimension(mm)

100.0 x 100.0
Thickness(mm)
3.0

Outer
Dimension(mm)

30.0 x 20.0
Thickness(mm)
3.0

Outer
Dimension(mm)

50.0 x 50.0
Thickness(mm)
3.0

Fiber
diameter (μm)
Size(mm) Products
φ 3 13.59 × 6.86
× 2.54t
J5734
Φ 6
(large end)
φ 12.5 - φ 25.0
× 25.0t
J5743
φ 6 φ 26.5
× 3.0t
J3182-74
J11057-74
30.0 × 20.0
× 3.0t
J3182-72
J11057-72
50.0 × 50.0
× 3.0t
J3182-73
J11057-73
100.0 × 100.0
× 3.0t
J11057-75
J11181-75
φ 25 φ 26.5
× 3.0t
J12221-74
30.0 × 20.0
× 3.0t
J12221-72
50.0 × 50.0
× 3.0t
J12221-73

We welcome your requests for custom FOPs with different
shapes and fiber diameters, etc. Please feel free to contact us.

Contact us for more information.
