The C10000-801 TDI camera is useful for a wide range of imaging applications requiring high speed operation with high sensitivity simultaneously. Also, frame readout mode is available for easy focusing.
This site provides information on scientific cameras.
Since there is a wide range of camera types and performance, it is important to select the best camera for each application.
It introduces technical information, simulation tools, and examples of actual applications to help you fully understand the performance of the camera and select the best one for your application.
|Imaging device||Back thinned type|
|Effective number of pixels||2048 (H)×128 (V)|
|Cell size||12 μm (H)×12 μm (V)|
|Effective area||24.58 mm (H)×1.536 mm (V)|
|Readout mode||TDI readout mode / frame readout mode*1|
|TDI transfer direction||Bidirectional transfer|
|TDI output channel||4 TAP (512×128)|
|Anti-blooming||Yes (100 times of the full well capacity)|
|TDI pixel clock rate||30 MHz|
|TDI line rate||0.457 kHz to 50 kHz|
|TDI line rate control||Internal setting by serial command*2 / External trigger|
|Full well capacity||80 000 electrons (typ.)|
|Readout noise||50 electrons rms (typ.)|
|Analog gain||1 time to 5 times (16 steps)|
|A/D converter||12 bit/8 bit*3|
|Image processing||Real-time shading correction / Back ground subtraction|
|Interface||Camera Link base configuration|
|Camera control||Serial control in Camera Link|
|Camera output clock||60 MHz|
|Camera output channel||2 TAP (1024×128)|
|Connector||Mini-Camera Link (SDR)×1|
|Power requirements||AC100 V to AC240 V, 50 Hz/60 Hz|
|Power consumption||Approx. 55 VA|
|Ambient operating temperature||0 ℃ to +40 ℃|
|Ambient storage temperature||-10 ℃ to +50 ℃|
|Ambient operating/storage humidity||90 % or less (with no condensation)|
|Ambient operating humidity||30 % to 70 % (with no condensation)|
