|Product Name||Mercury-xenon Lamp|
|Lamp Rating||200 W|
|Arc Length||2 mm|
|Lamp Current||8.0 A +/-0.5 A|
|Lamp Voltage||24 V|
|Window Material||Fused Silica|
|Spectral Distribution (Short)||185 nm|
|Spectral Distribution (Long)||2000 nm|
|Light Output Stability Drift Typ.||+/-0.5 %/h|
|Light Output Stability Fluctuation (p-p) Max.||2 %|
|Guaranteed Operation Life||1000 h|
|Average Life||2000 h|
|Orientation||Vertical +/-15 degree or Horizontal +/-15 degree|
|Cooling Method||Convection Cooling|
|Supply Voltage Min.||65 V dc|
|Trigger Voltage||20 kV|
