|Product Name||Xenon Lamp|
|Lamp Rating||300 W|
|Arc Length||3 mm|
|Lamp Current||15.0 A +/-1.0 A|
|Lamp Voltage||20 V|
|Window Material||Fused Silica|
|Spectral Distribution (Short)||185 nm|
|Spectral Distribution (Long)||2000 nm|
|Light Output Stability Drift Typ.||+/-0.5 %/h|
|Light Output Stability Fluctuation (p-p) Max.||1 %|
|Guaranteed Operation Life||1000 h|
|Average Life||2000 h|
|Orientation||Vertical +/-15 degree or Horizontal +/-15 degree|
|Cooling Method||Forced Cooling|
|Supply Voltage Min.||80 V dc|
|Trigger Voltage||25 kV|
