PSD module C10439-01 contains a high-precision two-dimensional PSD (position sensitive detector) and a low-noise amplifier, and is able to perform accurate distance measurement. Using a PSD module with a dedicated signal processing unit (C10460-01) allows obtaining distance information easily.
-Photosensitive area: 4 ×4 mm
-High precision analog voltage output
-Only half size of a business card: 34 (W) × 44 (H) × 40 (D) mm
-Three-types with different active areas available
|Detector type||Two-dimensional PSD|
|Photosensitive area||4 × 4 mm|
|Spectral response range||320 to 1100 nm|
|Peak sensitivity wavelength||960 nm|
|Photosensitivity (typ.)||-60 mV/μm|
|Supply voltage||±5 to ±12 V|
|Measurement condition||Ta=25 ℃, Vcc=±12 V, unless otherwise noted|
