Image intensifier

V13716U-N230

Specifications

Feature Second Generation
Spectral Response (Short) 160 nm
Spectral Response (Long) 320 nm
Spectral Response (Peak) 230 nm
Input Window Synthetic Silica
Index of Refraction 1.51
Effective Photocathode Area Dia.18 mm
Stage of MCP 2
Photocathode Material Cs-Te
Gate Function Non
Minimum Gate Time - ns
Radiant Sensitivity 59 mA/W
Quantum Efficiency (QE) 32 %
Radiant Emittance Gain 3.0 x 106 (W/m2)/(W/m2)
Equivalent Background Input (EBI) 4.0 x 10-15 W/cm2
Limiting Resolution 28 Lp/mm
Operation Ambient Temperature -20 to +40 ℃
Storage Ambient Temperature -55 to +60 ℃
Maximum Shock 300 m/s2 (30G), 18 ms
Maximum Vibration 10 Hz to 55 Hz, 0.35 mm (p-p)
