Photomultiplier tube assembly

H2431-50

60.0mm diameter PMT assembly, Built-in PMT:R2083, For high energy physics experiments, SHV connector

Specifications

Assembly Size Dia.60 mm
PMT Tube Size 51 mm
Built-in PMT Type No. R2083
Photocathode Area Shape Round
Photocathode Area Size Dia.46 mm
Wavelength (Short) 300 nm
Wavelength (Long) 650 nm
Wavelength (Peak) 420 nm
Spectral Response Curve Code 400K
Photocathode Material Bialkali
Window Material Borosilicate glass
Dynode Structure Linear-focused
Dynode Stages 8
[Max. Rating] Anode to Cathode Voltage -3500 V
[Max. Rating] Average Anode Current 0.61 mA
Anode to Cathode Supply Voltage -3000 V
[Cathode] Luminous Sensitivity Typ. 80 μA/lm
[Cathode] Blue Sensitivity Index (CS 5-58) Typ. 10
[Anode] Luminous Sensitivity Typ. 200 A/lm
[Anode] Gain Typ. 2.5 x 106
[Anode] Dark Current (after 30min.) Typ. 100 nA
[Anode] Dark Current (after 30min.) Max. 800 nA
[Time Response] Rise Time Typ. 0.8 ns
[Time Response] Transit Time Typ. 16 ns
[Time Response] Transit Time Spread Typ. 0.37 ns
[Anode] Pulse Linearity (2% deviation) 100 mA
[Anode] Pulse Linearity (5% deviation) 150 mA
