Microchannel plate photomultiplier tube


45mm dia., MCP-PMT, GaAs photocathode (Effective area :10 mm dia./Spectral response : 370 to 920 nm)


Tube Size Dia.45 mm
Photocathode Area Shape Round
Photocathode Area Size Dia.10 mm
Wavelength (Short) 370 nm
Wavelength (Long) 920 nm
Wavelength (Peak) 700 to 850 nm
Spectral Response Curve Code 602K
Photocathode Material GaAs
Window Material Borosilicate glass
Dynode Structure MCP
Dynode Stages 2
[Max. Rating] Anode to Cathode Voltage -3400 V
[Max. Rating] Average Anode Current 0.0001 mA
Anode to Cathode Supply Voltage -3000 V
[Cathode] Luminous Sensitivity Min. 400 μA/lm
[Cathode] Luminous Sensitivity Typ. 700 μA/lm
[Cathode] Radiant Sensitivity Typ. 77 mA/W
[Anode] Luminous Sensitivity Typ. 140 A/lm
[Anode] Gain Typ. 2.0 x 105
[Anode] Dark Current (after 30min.) Max. 25 nA
[Time Response] Rise Time Typ. 0.2 ns
[Time Response] Transit Time Typ. 0.55 ns
[Time Response] Transit Time Spread Typ. 0.15 ns
