Two-dimensional PSD

S5990-01

Improved tetra-lateral type for surface mounting






Features
-Large active area: 4 × 4 mm
-Chip carrier package for surface mounting thin package: 1.26 mmt
-Improved tetra-lateral type (pin-cushion type) delivers superior position detection
-Evaluation circuit boards provided (sold separately) C4674-01(DC signal processing circuit) ・Packing
 Tray: S5990-01
 Reel: S5990-11



Photosensitive area 4 x 4 mm
Package Ceramic
Peak sensitivity wavelength (typ.) 960 nm
Photosensitivity (typ.) 0.6 A/W
Package category Surface mount type
Spectral response range 320 to 1100
Dark current (max.) 10 nA
Rise time (typ.) 1 μs
Terminal capacitance (typ.) 70 pF
Interelectrode resistance (typ.) 7 kΩ
Measurement condition Typ. Ta=25 ℃, unless otherwise noted

Spectral response

Dimensional outline (unit: mm)
