CCD area image sensor
S11850-1106-01
Improved etaloning characteristics, Constant element temperature control
These are back-thinned CCD image sensors designed for spectrometers. Two types consisting of a low noise type (S11850-1106-01, S11850-1106-01) and high-speed type (S11851-1106-01) are available with improved etaloning characteristics. They offer nearly flat spectral response characteristics with high quantum efficiency from the UV to near infrared region. A thermoelectric cooler is placed inside the package to keep the element temperature constant (approx. 5 °C) during operation.
Features
-Improved etaloning characteristics
-One-stage TE-cooled type
(element temperature: approx. 5 °C)
-High sensitivity over a wide spectral range and nearly flat spectral response characteristics
-High CCD node sensitivity: 6.5 μV/e-
-High full well capacity, wide dynamic range
(with anti-blooming function)
-Pixel size: 14 × 14 μm
| Type | Binning type Low etaloning type |
|---|---|
| Image size | 28.672 x 0.896 mm |
| Number of effective pixels | 2048 x 64 pixels |
| Pixel size | 14 x 14 μm |
| Spectral response range | 200 to 1100 nm |
| Line rate (typ.) | 106 lines/s |
| Line rate (max.) | 200 lines/s |
| Dark current (typ.) | 50 e-/pixel/s |
| Readout noise (typ.) | 6 e- rms |
| Cooling | One-stage TE-cooled |
| Window material | Quartz glass |
| Package | Ceramic |
| Measurement condition | Typ. Ta=25 ℃, Dark current: MPP mode, unless otherwise noted |
Spectral response
Dimensional outline (unit: mm)
