Digital CMOS board level camera
The core of the C13770-50U camera is the scientific image sensor, an advanced CMOS detector that simultaneously achieves high resolution, fast readout speeds and low noise. With its small size, board-level design and simple, low-cost integration using USB 3.0, the C13770-50U is the ideal camera for OEM scientific imaging.
It is available to offer customization following your request. Please contact us for details.
|Imaging device||CMOS image sensor|
|Effective no. of pixels||2464 (H) × 2056 (V)|
|Cell size||3.45 μm (H) × 3.45 μm (V)|
|Effective area||8.50 mm (H) × 7.09 mm (V)|
|Full well capacity||10 500 electrons (typ.)|
|Readout speed||40 frames/s (Full resolution)
134 frames/s (2×2 Binning)
3406 frames/s (2×2 Binning, 4 Line Sub-array)
|Readout noise||2.3 electrons (rms) typ. (Analog gain 1×)|
|Exposure time||20.71 μs to 1 s (Internal trigger mode)
20.71 μs to 1 s (External trigger mode: Edge trigger, Start trigger)
1 ms to 1 s (External trigger mode: Level trigger, Synchronous readout trigger)
|Dynamic range||4565 : 1 typ.*1|
|Analog gain||1× to 15.8× (240 steps)|
|Binning||2 × 2 *2|
|External trigger mode||Edge trigger, Level trigger Synchronous readout trigger, Start trigger|
|Trigger delay function||0 s to 10 s in 1 μs steps|
|Trigger output||Programmable timing outputs Trigger ready output Global exposure timing output Low output, High output|
|Connector||USB 3.0 microB type|
|A/D converter||12 bit|
|Power supply||Bus Power/DC+8 V to DC+30 V|
|Power consumption||Approx. 4.5 W|
|Ambient operating temperature||0 ˚C to + 40 ˚C|
|Ambient storage temperature||- 10 ˚C to + 50 ˚C|
|Ambient operating humidity||30 % to 80 % (with no condensation)|
|Ambient storage humidity||90 % max. (with no condensation)|
