NanoZoomer S210 Digital slide scanner
The NanoZoomer series is a family of whole slide scanners that rapidly scan glass slides to convert them to digital data.
The newly developed the NanoZoomer S210 provides high performance capable of handling a large number of slides, yet at low cost without sacrificing the high-definition image quality and equipment reliability that made our NanoZoomer series popular with many users in the world.
*This model is NOT available in EU and UK.
|Product name||NanoZoomer S210|
|Scanning speeds: 20× mode (15 mm × 15 mm)||Approx. 60 s|
|Scanning speeds: 40× mode (15 mm × 15 mm)||Approx. 150 s|
|Objective lens||20× (NA 0.75)|
User can select 20× or 40× mode at start of scanning.
|Compatible glass slide||26 mm × 76 mm|
Thickness 0.9 mm to 1.2 mm
|Slide loader (standard size slide)||210 slides (30 slides × 7 cassettes)|
|Scanning resolution: 20× mode||0.46 μm/pixel|
|Scanning resolution: 40× mode||0.23 μm/pixel|
|Focusing method||Pre-focus map|
|Fluorescence imaging module||No|
|Barcode reader||1D barcode (standard feature), 2D barcode (option)|
|Slide format||JPEG compressed image + slide information|
|Power supply||AC100 V to AC240 V|
|Power consumption (scanner only)||Approx. 160 VA|
In the USA, C13220-01MD NanoZoomer S360MD Slide scanner system is intended for in vitro diagnostic use.
In Europe, following products are regulatory compliant for IVDR (EU), UKCA (UK) and IvDO (CH) for in vitro diagnostic use:
C13220-21MDEU NanoZoomer S360MD Slide scanner system, C16600-21MDEU NanoZoomer S60v2MD Slide scanner system and C16300-21MDEU NanoZoomer S20MD Slide scanner system.
In China, following products are registered for in vitro diagnostic use:
C13220-01 NanoZoomer S360, C13239-01 NanoZoomer S210, C13210-01 NanoZoomer S60 and C13140-01 NanoZoomer-SQ.
In Canada, C13220-31 NanoZoomer S360 has Medical Device License.
In Taiwan, C13220-01 NanoZoomer S360 is registered as medical device.
In Korea, C13220-61MDK NanoZoomer S360MD Slide scanner system is registered as in vitro diagnostic medical device.
In Japan, C13220-11MDJ Slide scanner system is approved as medical device.
For other countries, NanoZoomer series are for research use only and not permitted to use for clinical diagnostic purpose.
