FAQs (CMOS) | CCD / CMOS / NMOS image sensors

How should I store resin-sealed image sensors?

What is the difference between the dark output voltage and the output offset voltage of CMOS linear image sensors?

The dark output voltage is a dark current component mainly generated in pixels and increases in proportion to the integration time. The output offset voltage is a reference voltage that is output from the readout circuit (amplifier) and its value is constant, not proportional to the integration time.

Is it necessary to use a CDS circuit to signal-process the video output waveforms of CMOS linear image sensors?

No, it is not necessary to use a CDS circuit to signal-process the video output waveforms. Perform A/D conversion directly. In that case, connect an impedance converting buffer amplifier to the video output terminal and as much as possible do not allow current to flow. As the buffer amplifier, use a high input impedance op amp of JFET input or CMOS input.

What kind of resin is used for resin-sealed CMOS image sensors?

See the table below.For information on products not listed in the above table, check the delivery specification sheet or contact our sales office.

Epoxy resin Sillicone resin
S10226
S10227
S11106
S11107
S10226-10
S10227-10
S11106-10
S11107-10
S12443

What is the refractive index of resin used for resin-sealed CMOS image sensors?

Epoxy resin Sillicone resin
1.558 (589 nm) 1.539 (587 nm)

Contact us for more information.
