Xenon lamp

L14284

35 W, Spectral distribution : 185 nm to 2000 nm, Short gap

Specifications

Product Name Xenon Lamp
Lamp Rating 35 W
Arc Length 1 mm
Lamp Current 3.5 A +/-0.2 A
Lamp Voltage 11 V
Window Material Low ozone fused silica
Spectral Distribution (Short) 185 nm
Spectral Distribution (Long) 2000 nm
Light Output Stability Drift Typ. +/-0.5 %/h
Light Output Stability Fluctuation (p-p) Max. 1 %
Guaranteed Operation Life 1000 h
Average Life 2000 h
Orientation Vertical +/-15 degree or Horizontal +/-15 degree
Cooling Method Convection Cooling
Supply Voltage Min. 50 V dc
Trigger Voltage 15 kV
Weight 14 g
