Xenon lamp

L14285-01

75 W, Spectral distribution : 185 nm to 2000 nm

Specifications

Product Name Xenon Lamp
Lamp Rating 75 W
Arc Length 1.3 mm
Lamp Current 5.4 A +/-0.5 A
Lamp Voltage 15 V
Window Material Low ozone fused silica
Spectral Distribution (Short) 185 nm
Spectral Distribution (Long) 2000 nm
Light Output Stability Drift Typ. +/-0.5 %/h
Light Output Stability Fluctuation (p-p) Max. 1 %
Guaranteed Operation Life 1000 h
Average Life 2000 h
Orientation Vertical +/-15 degree or Horizontal +/-15 degree
Cooling Method Convection Cooling
Supply Voltage Min. 50 V dc
Trigger Voltage 15 kV
Weight 15 g
