Mercury-xenon lamp

L2483

350 W, Spectral distribution : 185 nm to 2000 nm

Specifications

Product Name Mercury-xenon Lamp
Lamp Rating 350 W
Arc Length 2.5 mm
Lamp Current 14.0 A +/-1.0 A
Lamp Voltage 25 V
Window Material Fused Silica
Spectral Distribution (Short) 185 nm
Spectral Distribution (Long) 2000 nm
Light Output Stability Drift Typ. +/-0.5 %/h
Light Output Stability Fluctuation (p-p) Max. 2 %
Guaranteed Operation Life 500 h
Average Life 1000 h
Orientation Vertical +/-15 degree
Cooling Method Forced Cooling
Supply Voltage Min. 70 V dc
Trigger Voltage 25 kV
Weight 68 g
