LIGHTNINGCURE LC-L1V5
L14310 / L14311 / C14052 series
Compact body easily installs into narrow confined spaces.
We came up with a unit that drives 4 heads but is small enough to fit in the palm of your hand. This unit can also be freely placed standing or horizontal in just a tiny space, so it needs no special layout. Our unique feedback function minimizes drift during initial light emission period and constantly maintains fluctuations in light output within 5 %.
Specifications
LED head unit L14310 series
| Parameter | Standard type | Unit | |||||
|---|---|---|---|---|---|---|---|
| Irradiation area φ3 mm type |
Irradiation area φ6 mm type |
Irradiation area φ8 mm type |
Irradiation area φ12 mm type |
||||
| L14310-□10 (*1) (*2) |
L14310-□15 (*1) (*2) |
L14310-□20 (*1) (*2) |
L14310-□00 (*1) (*2) |
||||
| Mounted condenser lens | E11923-010 | E11923-015 | E11923-020 | — | — | ||
| Focal length | 10 | 15 | 20 | 10 | mm | ||
| Irradiation area (*3) | Approx. φ3 | Approx. φ6 | Approx. φ8 | Approx. φ10 | mm | ||
| Wavelength | 365 / 385 / 405 | nm | |||||
| UV irradiance (*4) | 14000 | 6500 | 4000 | 1000 | mW/cm2 | ||
| LED design life (*5) | 20000 | h | |||||
| Cooling method | Not required | － | |||||
| Operating temperature range | +5 ℃ to +40 ℃ | － | |||||
| Storage temperature range | -10 ℃ to +60 ℃ (no freezing) | － | |||||
| Operating humidity range | 20 % to 80 % (no condensation) | － | |||||
| Storage humidity range | Below 80 % (no condensation) | － | |||||
| Applicable standards | EMC standards | IEC 61326-1 Emission limits: CISPR 11 Group 1 Class A Immunity requirements: Table 2 |
— | ||||
| Safety standards | IEC/EN 61010-1/A1 | ||||||
*1: This type number indicates a combination of L14310-□00 LED head unit and E11923 series condenser lens.
The focal length and irradiation area can be changed by replacing the E11923 series condenser lens.
*2: The square symbol □ in each type number indicates a suffix that represents the wavelength.
1: 365 nm, 2: 385 nm, 4: 405 nm.
*3: Irradiation area measured at the focal length.
*4: Maximum UV irradiance within the irradiated area measured at the focal length.
*5: Average time required for UV irradiance to reach 70 % of the initial value at an operating temperature of 25 ℃.
LED head unit L14311 series
| Parameter | Right-angle type | Linear beam type | |||||
|---|---|---|---|---|---|---|---|
| Mid focal length type | Long focal length type | Wide range type | |||||
| L14311-□03 (*2) | L14311-□05 (*2) | L14311-□02 (*2) | L14311-□04 (*2) | ||||
| Mounted condenser lens | — | — | — | — | — | ||
| Focal length | 10 | 20 | 15 | 10 | mm | ||
| Irradiation area (*3) | Approx. φ6 | Approx. φ7 | Approx. φ20 x 6 | Approx. φ12 x 4 | mm | ||
| Wavelength | 365 / 385 / 405 | nm | |||||
| UV irradiance (*4) | 4000 | 3000 | 1200 | 3000 | mW/cm2 | ||
| LED design life (*5) | 20000 | h | |||||
| Cooling method | Not required | － | |||||
| Operating temperature range | +5 ℃ to +40 ℃ | － | |||||
| Storage temperature range | -10 ℃ to +60 ℃ (no freezing) | － | |||||
| Operating humidity range | 20 % to 80 % (no condensation) | － | |||||
| Storage humidity range | Below 80 % (no condensation) | － | |||||
| Applicable standards | EMC standards | IEC 61326-1 Emission limits: CISPR 11 Group 1 Class A Immunity requirements: Table 2 |
— | ||||
| Safety standards | IEC/EN 61010-1/A1 | ||||||
*2: The square symbol □ in each type number indicates a suffix that represents the wavelength.
1: 365 nm, 2: 385 nm, 4: 405 nm.
*3: Irradiation area measured at the focal length.
*4: Maximum UV irradiance within the irradiated area measured at the focal length.
*5: Average time required for UV irradiance to reach 70 % of the initial value at an operating temperature of 25 ℃.
Condenser lens E11923 series
| Parameter | E11923-010 | E11923-015 | E11923-020 | Unit | ||
|---|---|---|---|---|---|---|
| Focal length | 10 | 15 | 20 | mm | ||
| Irradiation area (*6) | Approx. φ3 | Approx. φ6 | Approx. φ8 | mm | ||
| Operating temperature range | +5 ℃ to +40 ℃ | － | ||||
| Storage temperature range | -10 ℃ to +60 ℃ (no freezing) | － | ||||
| Operating humidity range | 20 % to 80 % (no condensation) | － | ||||
| Storage humidity range | Below 80 % (no condensation) | － | ||||
*6: Irradiation area measured at the focal length.
Controller C14052 series
| Parameter | C14052-0-□□ (*7) | C14052-1-□□ (*7) | C14052-2-□□ (*7) | Unit | ||
|---|---|---|---|---|---|---|
| Input voltage (AC) | 100 V to 240 V, single phase 50 Hz / 60 Hz (*8) | — | ||||
| Power consumption (*9) | Max. | 25 | W | |||
| Cooling method | Not required | — | ||||
| Operating temperature range | +5 ℃ to +40 ℃ | － | ||||
| Storage temperature range | -10 ℃ to +60 ℃ (no freezing) | － | ||||
| Operating humidity range | 20 % to 80 % (no condensation) | － | ||||
| Storage humidity range | Below 80 % (no condensation) | － | ||||
| External control | Irradiation control, irradiation signal, various error signals | — | ||||
| Communication control | N/A | Control via USB | Control via RS-232C | — | ||
| — | Irradiation control, irradiation signal, accumulation / display / reset of irradiation time, program setting for auto irradiation, various error signals |
|||||
| Applicable standards | EMC standards | IEC 61326-1 Emission limits: CISPR 11 Group 1 Class A Immunity requirements: Table 2 |
— | |||
| Safety standards | IEC/EN 61010-1/A1 | |||||
*7: The square symbol □ in each type number indicates a suffix that represents the specifications of the AC adapter.
・When no AC adapter supplied, no suffix is added. The user needs to prepare an AC adapter that outputs 12 V DC and 24 W or more.
In that case, EMC and safety testing should be performed by the user.
・When an AC adapter supplied, a suffix is added. A1: For Japan, A2: For U.S., A3: For Europe, A4: For China, A5: UK, A7: Thailand
In the case of C14052-0, the "-0" will be omitted and so the type number will be C14052.
*8: Input voltage to the controller should be 12 V ±0.5 V DC.
*9: Power consumption when 4 heads are operated.
Characteristics
Irradiance distributions (Typ. 365 nm)
Standard type: Irradiation area φ3 mm type
Standard type: Irradiation area φ6 mm type
Standard type: Irradiation area φ8 mm type
Standard type: Irradiation area φ12 mm type
NOTE: The center of the external dimensions of the LED head unit may not coincide with the center of the irradiated light. Adjust the installation position as needed.
The shape of the irradiated light varies depending on the irradiation distance, for example, becomes close to a square.
There are individual differences in the irradiance distribution between LED head units due to variations in the emission intensity of LED elements.
Demo unit loaning
Demo unit is available.
Please click below and contact us for the details.
