Image intensifier tube

V13716U-N130

Image intensifiers are devices that can detect and amplify very low levels of light to capture images.

They are used in a wide range of applications, including imaging of micro-discharges in the invisible regions and observation of high-speed phenomena.

The V13716U-N130 is high sensitivity Cs-Te photocathode image intensifier with spectral response range from 160 nm to 320 nm and an effective photocathode area of Φ18 mm.

Specifications

Feature Second Generation
Spectral Response (Short) 160 nm
Spectral Response (Long) 320 nm
Spectral Response (Peak) 230 nm
Input Window Synthetic Silica
Index of Refraction 1.51
Effective Photocathode Area Dia.18 mm
Stage of MCP 1
Photocathode Material Cs-Te
Gate Function Non
Minimum Gate Time - ns
Radiant Sensitivity 59 mA/W
Quantum Efficiency (QE) 32 %
Radiant Emittance Gain 7.3 x 103 (W/m2)/(W/m2)
Equivalent Background Input (EBI) 1.0 x 10-15 W/cm2
Limiting Resolution 40 Lp/mm
Operation Ambient Temperature -20 to +40 ℃
Storage Ambient Temperature -55 to +60 ℃
Maximum Shock 300 m/s2 (30G), 18 ms
Maximum Vibration 10 Hz to 55 Hz, 0.35 mm (p-p)
