Image intensifier tube

V4170U-03

Image intensifiers are devices that can detect and amplify very low levels of light to capture images.

They are used in a wide range of applications, including imaging of micro-discharges in the invisible regions and observation of high-speed phenomena.

The V4170U-03 is Cs-Te photocathode image intensifier with spectral response range from 160 nm to 320 nm and an effective photocathode area of Φ18 mm.

Specifications

Feature Second Generation
Spectral Response (Short) 160 nm
Spectral Response (Long) 320 nm
Spectral Response (Peak) 230 nm
Input Window Synthetic Silica
Index of Refraction 1.51
Effective Photocathode Area Dia.18 mm
Stage of MCP 2
Photocathode Material Cs-Te
Gate Function Without
Minimum Gate Time
Luminous Sensitivity
Radiant Sensitivity 32 mA/W
Quantum Efficiency (QE) 17 %
Luminous Gain
Radiant Emittance Gain 1.6 x 106 (W/m2)/(W/m2)
Equivalent Background Input (EBI)
Equivalent Background Input (EBI) 1.0 x 10-15 W/cm2
Limiting Resolution 28 Lp/mm
Operation Ambient Temperature -20 to +40 ℃
Storage Ambient Temperature -55 to +60 ℃
Maximum Shock 300 m/s2 (30G), 18 ms
Maximum Vibration 10 Hz to 55 Hz, 0.35 mm (p-p)
