MPPC array
S13363-3050NE-16
One-dimensional 16 ch array, Pixel pitch: 50 μm
The S13363-3050NE-16 is a miniaturized one-dimensional 16 ch MPPC array using TSV (through-silicon via) and CSP (chip size package) technologies. The product has an effective photosensitive area of 3 × 3 mm per channel. The gap between channels is narrowed and the dead area is reduced. This is suitable for applications, such as nuclear medical, non-destructive inspection, and high energy physics experiment, that require photon counting measurement.
Features
-Low crosstalk
-Low afterpulses
-Low voltage (VBR=53 V typ.) operation
-High gain: 1.7 × 106 typ.
Specifications
| Package type | Surface mount type |
|---|---|
| Number of channels | 16 ch |
| Effective photosensitive area / ch | 3 × 3 mm |
| Number of pixels /ch | 3584 |
| Pixel size | 50 μm |
| Spectral response range | 320 to 900 nm |
| Peak sensitivity wavelength (typ.) | 450 nm |
| Dark count/ch (typ.) | 500 kcps |
| Terminal capacitance/ch (typ.) | 320 pF |
| Gain (typ.) | 1.7×106 |
| Measurement condition | Ta=25 ℃, Dark count rate: VR=Vop, Terminal capacitance: VR=Vop, f=100 kHz, Gain: VR=Vop, unless otherwise noted |
Dimensional outline (unit: mm)
