Si PIN photodiode
The S10784 is a high-speed APC (auto power control) detector developed for monitoring laser diodes with a peak wavelength of 660 nm or 780 nm.
|Photosensitive area||φ3.0 mm|
|Number of elements||1|
|Reverse voltage (max.)||20 V|
|Spectral response range||340 to 1040 nm|
|Peak sensitivity wavelength (typ.)||760 nm|
|Photosensitivity (typ.)||0.51 A/W|
|Dark current (max.)||1000 pA|
|Cutoff frequency (typ.)||250 MHz|
|Terminal capacitance (typ.)||4.5 pF|
|Noise equivalent power (typ.)||3.5×10-15 W/Hz1/2|
|Measurement condition||Ta=25 ℃, Typ., Photosensitivity: λ=780 nm, Dark current: VR=2.5 V, Cutoff frequency: VR=2.5 V, λ=780 nm, Terminal capacitance: VR=2.5 V, f=1 MHz, Noise equivalent power: VR=2.5 V, unless otherwise noted|
