Si photodiode

S8193

Detector for X-ray monitors



Features
- High sensitivity, high reliability photodiode with ceramic scintillator
- High X-ray sensitivity: 1.8 times that of CWO
- Less afterglow than CsI: <0.1 %/3 ms, <0.01 %/30 ms
- Unlike CsI, has no deliquescence

Photosensitive area 5.8 × 5.8 mm
Package Ceramic
Package category With scintillator
Cooling Non-cooled
Reverse voltage (max.) 5 V
Dark current (max.) 50 pA
Terminal capacitance (typ.) 950 pF

Dimensional outline (unit: mm)
