NanoZoomer-SQ Digital slide scanner
The NanoZoomer is a family of whole slide scanners that convert glass slides into high-resolution digital data by high-speed scanning.
NanoZoomer-SQ is Hamamatsu’s new desktop single slide scanner for creating whole slide images of single tissue slides. Its very compact size makes it suitable even for the smallest lab, while maintaining the well renowned reliability and robustness of Hamamatsu whole slide scanners.
|Scanning speeds: 20× mode (15 mm × 15 mm)||Approx. 150 s|
|Scanning speeds: 40× mode (15 mm × 15 mm)||Approx. 275 s|
|Objective lens||20× (NA 0.75)|
User can select 20× or 40× mode at start of scanning.
|Compatible glass slide||26 mm × 76 mm|
Thickness 0.9 mm to 1.2 mm
|Slide loader (standard size slide)||1 slide|
|Scanning resolution: 20× mode||0.46 μm/pixel|
|Scanning resolution: 40× mode||0.23 μm/pixel|
|Focusing method||Pre-focus map|
|Fluorescence imaging module||No|
|Barcode reader||1D barcode (standard feature), 2D barcode (option)|
|Slide format||JPEG compressed image + slide information|
|Power supply voltage||AC100 V to AC240 V|
|Power consumption||Approx. 72 VA|
In the USA, C13220-01MD NanoZoomer S360MD Slide scanner system is intended for in vitro diagnostic use.
In Europe, following products are regulatory compliant for IVDR (EU), UKCA (UK) and IvDO (CH) for in vitro diagnostic use:
C13220-21MDEU NanoZoomer S360MD Slide scanner system, C16600-21MDEU NanoZoomer S60v2MD Slide scanner system and C16300-21MDEU NanoZoomer S20MD Slide scanner system.
In China, following products are registered for in vitro diagnostic use:
C13220-01 NanoZoomer S360, C13239-01 NanoZoomer S210, C13210-01 NanoZoomer S60 and C13140-01 NanoZoomer-SQ.
In Canada, C13220-31 NanoZoomer S360 has Medical Device License.
In Taiwan, C13220-01 NanoZoomer S360 is registered as medical device.
In Korea, C13220-61MDK NanoZoomer S360MD Slide scanner system is registered as in vitro diagnostic medical device.
In Japan and other countries, NanoZoomer series are for research use only and not permitted to use for clinical diagnostic purposes.
