PSD module

C10443-02

Integrates a PSD for precision photometry with low-noise amp in a compact case (Photosensitive area: 9 ×9 mm)



PSD modules C10443-02 contains a high-precision two-dimensional PSD (position sensitive detector) and a low-noise amplifier, and is able to perform accurate distance measurement. Using a PSD module with a dedicated signal processing unit (C10460) allows obtaining distance information easily.


Features
-Photosensitive area: 9 ×9 mm
-Easy handling
-High precision analog voltage output
-Only half size of a business card: 34 (W) × 44 (H) × 40 (D) mm
-Three-types with different active areas available



Detector type Two-dimensional PSD
Photosensitive area 9 × 9 mm
Peak sensitivity wavelength Two-dimensional PSD
Spectral response range 320 to 1100 nm
Peak sensitivity wavelength 960 nm
Photosensitivity (typ.) -60 mV/μm
Supply voltage ±5 to ±12 V
Measurement condition Ta=25 ℃, Vcc=±12 V, unless otherwise noted

Spectral response

Dimensional outline (unit: mm)
