|Product Name||Xenon Lamp|
|Lamp Rating||75 W|
|Arc Length||1.3 mm|
|Lamp Current||5.4 +/- 0.5 A|
|Lamp Voltage||15 V|
|Window Material||Fused Silica|
|Spectral Distribution (Short)||185 nm|
|Spectral Distribution (Long)||2000 nm|
|Light Output Stability Drift Typ.||+/- 0.5 %/h|
|Light Output Stability Fluctuation (p-p) Max.||1 %|
|Guaranteed Operation Life||1000 h|
|Average Life||2000 h|
|Orientation||Vertical +/-15 or Horizontal +/-15 degree|
|Cooling Method||Convection Cooling|
|Supply Voltage Min.||50 V dc|
|Trigger Voltage||15 kV|
