|Product Name||Xenon Lamp|
|Lamp Rating||150 W|
|Arc Length||2 mm|
|Lamp Current||8.5 A +/-0.5 A|
|Lamp Voltage||17 V|
|Window Material||Fused Silica|
|Spectral Distribution (Short)||185 nm|
|Spectral Distribution (Long)||2000 nm|
|Light Output Stability Drift Typ.||+/-0.5 %/h|
|Light Output Stability Fluctuation (p-p) Max.||0.01|
|Guaranteed Operation Life||1800 h|
|Average Life||3000 h|
|Orientation||Vertical +/-15 or Horizontal +/-15 degree|
|Cooling Method||Convection Cooling|
|Supply Voltage Min.||65 V dc|
|Trigger Voltage||20 kV|
