Mercury-xenon lamp

L2423

200 W, Spectral distribution : 185 nm to 2000 nm

Specifications

Product Name Mercury-xenon Lamp
Lamp Rating 200 W
Arc Length 2 mm
Lamp Current 8.0 A +/-0.5 A
Lamp Voltage 24 V
Window Material Fused Silica
Spectral Distribution (Short) 185 nm
Spectral Distribution (Long) 2000 nm
Light Output Stability Drift Typ. +/-0.5 %/h
Light Output Stability Fluctuation (p-p) Max. 2 %
Guaranteed Operation Life 1000 h
Average Life 2000 h
Orientation Vertical +/-15 degree or Horizontal +/-15 degree
Cooling Method Convection Cooling
Supply Voltage Min. 65 V dc
Trigger Voltage 20 kV
Weight 45 g
