Microfocus X-ray source
|Tube Voltage||100 kV|
|Tube Voltage Operational Range||40 to 100 kV|
|Maximum Output||20 W|
|X-ray Focal Spot Size||5 to 30 (5um at 4W) μm|
|X-ray Beam Angle (Coned)||42 degree|
|Focus to Object Distance (FOD)||6.8 mm|
