|Parameter||Discription / Value||Unit|
|Soft X-ray tube||Tube voltage (DC)||9.5||kV|
|X-ray emission angle||130||°|
|Input voltage||DC24 V||－|
|Power consumption (Max.)||7||W|
|Operating temperature range||0 to +40||℃|
|Storage temperature range||-10 to +60||℃|
|Operating humidity range||Below 60 % (no condensation)||-|
|Storage humidity range||Below 85 % (no condensation)||-|
|Applicable standards||EMC||IEC 61326-1:2013, Group 1, Class A||-|
|Environment||RoHS directive, WEEE directive||-|
