Infrared detector module with preamp
This device combine a dewar type detector with a compatible preamplifier, and easily operate to detect infrared radiation just by connecting to a DC power supply. Custom-designed devices with different active areas, FOV or amplifier gain, etc. are also available to meet your specific needs.
- Compact integral detector unit
- Optimum connections between the detector element and preamplifier allow amplified signals to be easily obtained.
|Type||Metal dewar type|
|Built-in sensor||Type Ⅱ superlattice detector|
|Photosensitive area||φ0.1 mm|
|Cutoff wavelength (typ.)||14.5 μm|
|Peak sensitivity wavelength (typ.)||5.4 μm|
|Measurement condition||Typ. T=-196 ℃, unless otherwise noted|
