InSb photovoltaic detector
The P5968-200 is a photovoltaic detector having high sensitivity in the so-called atmospheric window at 3 to 5 μm. Custom devices are also available to meet your special request.
|Photosensitive area||φ2 mm|
|Number of elements||1|
|Rise time (typ.)||150 ns|
|Measurement condition||Td=-196 ℃, Detectivity D*: λ=λp, fc=1200 Hz, Δf=1 Hz|
