MPPC module


Optical measurement modules for low-level-light detection, Analog output

The C13365 series are optical measurement modules capable of detecting low level light. These modules consist of an MPPC, a signal amplifier circuit, a high-voltage power supply circuit, and a temperature compensation circuit. The photosensitive area is 3 × 3 mm, and the signal output is analog. Modules operate just by connecting them to an external power supply (±5 V).

-Built-in MPPC for precision measurement
-High sensitivity in the short wavelength range
-Low noise equivalent power
-Built-in temperature compensation circuit
-Compact and lightweight
-Analog output

Built-in sensor S13360-3050CS
Cooling Non-cooled
Effective photosensitive area/ch 3 x 3 mm
Number of pixels/ch 3600
Number of channels 1 ch
Pixel pitch 50 μm
Note Analog output
Measurement condition Ta=25 ℃

Dimensional outline (unit: mm)
