Evaluation circuit for optics module


Dedicated evaluation circuit for the optics module (C13398 series)

The C13390 is a dedicated evaluation circuit for the optics module (C13398 series). When the C13390 is connected to the PC through USB, the analog output signals of each channel of the C13398 series can be converted into digital signals, and the results can be acquired into the PC. Both the C13398 series and the C13390 can be driven off of USB bus power. There is no need to prepare a separate power supply or the like. You can simply connect it to the PC through USB and perform evaluation and measurement.

- High-resolution digital output (16-bit)
- Up to 10 channels of output signals can be acquired into a PC.
- USB bus powered
- Built-in power supply circuit for driving the C13398 series

Dimensional outline (unit: mm)
