S12915 series have high sensitivity in the visible range to near IR.
They provide higher sensitivity than the S2387 series and can be used in high-humidity environments.
|Window material||Plastic potting||-|
|Package||8.9 × 10.1||mm|
|Photosensitive area size||5.8 × 5.8||mm|
|Effective photosensitive area||33||mm2|
|Reverse voltage Max.||30||V|
|Operating temperature||-20 ～ +60||℃|
|Storage temperature||-20 ～ +80||℃|
|Spectral response range||340 ～ 1100||nm|
|Peak sensitivity wavelength||960||nm|
|Short circuit current Typ.||33||31||μA|
|Dark current Max.||50||pA|
|Temp. coefficient of ID||1.12||times/℃|
|Rise time Typ.||9||10||μs|
|Terminal capacitance Typ.||4000||4300||pF|
|Shunt resistance Typ.||10||GΩ|
|Noise equivalent power||2.0 × 10-15||2.2 × 10-15||W/Hz1/2|
|Measurement conditions||Typ. Ta=25 ℃, Photosensitivity: λ=λp, Dark current: VR=10 mV, Rise time: VR=0 V, f=10 kHz, Shunt resistance: VR=10 mV, Noise equivalent power: VR=0 V, λ=λp, unless otherwise noted|
