Hybrid photo detector
|Spectral response||380 to 900||nm|
|Window material||Borosilicate glass||―|
|Avalanche diode (AD) reverse bias voltage||Max.||Vb -10||V|
|Average photocathode current||Max.||200||pA|
|Quantum efficiency (at 800 nm)||Typ.||15||%|
|AD leakage current||Typ.||150||pA|
|Gain||Typ.||1.2 x 105||―|
|Time response||Rise time||Typ.||400||ps|
|T.T.S (Transit Time Spread) (FWHM)||130||ps|
|Operating ambient temperature||+15 to +35||℃|
|Storage temperature||0 to +40||℃|
