Power supply unit for driving photomultiplier tube modules. Both drive voltages and control voltages can be supplied from this one unit.
|Parameter||Description / Value||Unit|
|Max. output current||2.0||0.2||A|
|Max. Vref input (VREF)||+1.8||V|
|Vcont output (CONTROL) *¹||+0.25 to +1.8||V|
|Terminal connection method||Binding post||-|
|AC input voltage *²||100 to 240||V|
|AC input frequency||50 / 60||Hz|
|Max. AC input current consumption||0.5||A|
|Operating ambient temperature *³||+5 to +50||℃|
|Operating ambient humidity *³||Below 80||%RH|
|Storage temperature *³||-20 to +50||℃|
|Storage humidity *³||Below 80||%RH|
*1: Adjust within the recommended Vcont range for the photomultiplier tube module being used.
*2: According to the applicable safety standard of the supplied power code.
*3: No condensation.
