|Type||Metal package type|
|Tube Size||30 x 30 mm|
|Photocathode Area Shape||Square|
|Photocathode Area Size||23 x 23 mm|
|Wavelength (Short)||300 nm|
|Wavelength (Long)||920 nm|
|Wavelength (Peak)||530 nm|
|Spectral Response Curve Code||501K|
|Photocathode Material||Extended red multialkali|
|Window Material||Borosilicate glass|
|Dynode Structure||Metal channel|
|[Max. Rating] Anode to Cathode Voltage||1000 V|
|[Max. Rating] Average Anode Current||0.1 mA|
|Anode to Cathode Supply Voltage||900 V|
|[Cathode] Luminous Sensitivity Min.||350 μA/lm|
|[Cathode] Luminous Sensitivity Typ.||500 μA/lm|
|[Cathode] Red/White Ratio (R-68) Typ.||0.4|
|[Cathode] Radiant Sensitivity Typ.||78 mA/W|
|[Anode] Luminous Sensitivity Min.||250 A/lm|
|[Anode] Luminous Sensitivity Typ.||1200 A/lm|
|[Anode] Radiant Sensitivity Typ.||1.8 x 105 A/W|
|[Anode] Gain Typ.||2.4 x 106|
|[Anode] Dark Current (after 30min.) Typ.||30 nA|
|[Anode] Dark Current (after 30min.) Max.||200 nA|
|[Time Response] Rise Time Typ.||1.3 ns|
|[Time Response] Transit Time Typ.||5.8 ns|
|[Time Response] Transit Time Spread Typ.||0.27 ns|
|[Anode] Pulse Linearity (2% deviation)||20 mA|
|[Anode] Pulse Linearity (5% deviation)||60 mA|
