OPAL‐Luxe High dynamic range spectrometer


The OPAL-Luxe is a compact, multi-channel spectrometer with the unprecedented ultra-high dynamic range. It is capable of simultaneous multi-wavelength spectral measurements over a wide wavelength range with extremely high dynamic range, and is particularly effective when strong and weak signals are present simultaneously. In order to take full advantage of its high dynamic range, the spectral optics have been newly designed and developed as a top-of-the-line model of, with high sensitivity, high wavelength resolution, while minimizing stray light.

(This product name might be changed in China and Korea.)


News about OPAL-Luxe


OPAL-Luxe Named LASER World of PHOTONICS Innovation Award 2023 Sensors, test and measurement / Optical Measuring System / Imaging Finalist





Wavelength 200 nm to 900 nm
Wavelength resolution (FWHM) ≤ 0.9 nm (typ.0.85 nm)

Wavelength accuracy

±0.1 nm
Exposure time 100 μs to 32.7 s
Repetition frequency 100 Hz
Number of photosensitive device channels 2048 ch
Pixel size 12 μm × 1536 μm
Device cooling temperature −5 °C
Readout noise (typ.) 12 electrons rms
Dark current (typ.) 1.5 electrons/pixel/sec (−5 °C)
Dynamic range (typ.) 2 500 000:1
AD resolution 16 bit
Spectrograph F number 2.2
External trigger input TTL level/High impedance (D-sub 15-pin connector)
Interface Ethernet (CAT.6) within 30 m
Power supply DC24 V
Power consumption Approx. 40 VA
Ambient operating temperature +10 °C to +35 °C
Ambient operating humidity 30 % to 80 % (With no condensation)
