Microfocus X-ray source
|Tube Voltage||90 kV|
|Tube Voltage Operational Range||20 to 90 kV|
|Maximum Output||8 W|
|X-ray Focal Spot Size||7 (5um at 4W) μm|
|X-ray Beam Angle (Coned)||39 degree|
|Focus to Object Distance (FOD)||9.5 mm|
