The S14160 series achieve higher PDE (photon detection efficiency) and lower operation voltage than other MPPC to adapt for PET and radiation monitor application. They achieve small dead space in a photosensitive area with HWB (hole wire bonding) technology (Patent pending). And the gap from the photosensitive area edge to the package edge is only 0.2 mm. This package realizes the four-side buttable arrangement.
|Package type||Surface mount type|
|Number of channels||1 ch|
|Effective photosensitive area / ch||4 × 4 mm|
|Number of pixels /ch||6331|
|Pixel size||50 μm|
|Spectral response range||270 to 900 nm|
|Peak sensitivity wavelength (typ.)||450 nm|
|Terminal capacitance/ch (typ.)||900 pF|
|Measurement condition||Ta=25 ℃|
