The mini-spectrometer TF series is a polychromator provided in a compact, thin case that houses optical elements, image sensor, and driver circuit. Spectrum data can be acquired by guiding measurement light into a mini-spectrometer through an optical fiber and transferring the measured results to a PC via the USB connection. The incorporation of a high-sensitivity CMOS image sensor maintains high sensitivity equivalent to that of a CCD and achieves low power consumption. Moreover, the trigger function that can be also used for short-term integration enables spectroscopic measurement of pulse emissions. The product includes free evaluation software with functions for setting measurement conditions, acquiring and saving data, drawing graphs, and so on. Furthermore, the DLL function specifications are disclosed, so users can create their original measurement software programs.
- Compact, thin case
- High-sensitivity CMOS image sensor built in
(high sensitivity equivalent to that of a CCD)
- With a trigger function
- High throughput using quartz transmission grating
- Highly accurate optical characteristics
- External power supply not necessary (USB bus powered)
- Installable in equipment
- Stores wavelength conversion factor in internal memory
|Spectral response range||340 to 830 nm|
|Spectral resolution (FWHM) (typ.)||2.3 nm|
|Spectral resolution (FWHM) (max.)||3 nm|
|A/D resolution||16 bits|
|Built-in sensor||High-sensitivity CMOS linear image sensor|
|Number of total pixels||512 pixels|
|Measurement condition||Typ. Ta=25 ℃, unless otherwise noted|
