ORCA-Fusion BT Digital CMOS camera

C15440-20UP

null

See what you’ve been missing

The ORCA-Fusion BT camera is the pinnacle of scientific CMOS (sCMOS) performance. The specifications are without compromise: ultra-low readout noise, CCD-like uniformity, fast frame rates and back-thinned enabled high QE. But the beauty of the ORCA-Fusion BT is what this combination of exceptional photon detection and collection can do for you. See the dimmest whisper of signal, acquire visually stunning, high S/N images from the fewest photons, capture previously unresolved temporal events and perform computational methods with confidence. The ORCA-Fusion BT is the camera that makes the difficult experiments easy and previously impossible experiments possible.

If you like the product on this page, save it to your wishlist.

Special sites

The life science camera section is the feature section for digital cameras fit to life science research and industry areas.

Special site for life science cameras

ORCA-Fusion BT advantages versus other BT CMOS cameras

Exclusive industry leading BT sCMOS performance with trusted Hamamatsu quality and reliability

  • Extremely low readout noise
  • High QE, across a wide range of wavelengths
  • CCD-like uniformity; minimal high readout noise pixels
  • High dynamic range
  • 3 readout speeds
  • Lightsheet readout mode
  • 5.3 Megapixels
  • Both USB 3.0 and high speed CoaXPress interfaces

ORCA-Fusion BT advantages versus EM-CCD cameras

A practical and functional replacement for expensive EM-CCDs with uncompromising sensitivity, speed and versatility

  • Resolution
  • Binning versatility
  • No amplification or excess noise
  • High dynamic range
  • Large field of view

Applications

  • Wide-field fluorescence microscopy
  • Time-lapse imaging
  • Spinning disk confocal microscopy
  • Lightsheet microscopy
  • Super resolution precision localization
  • Genetically encoded voltage imaging
  • Optogenetics
  • Single molecule tracking
  • Computational imaging
  • Quantum computing

Time-lapse live cell imaging by low light excitation

Sample: H9c2, Objective lens: Apo TIRF 60XC (NA1.49), ND: 8, Interval: 15 sec

Nucleus

c15440-20up Application example 1

Nucleus:
HCS NuclearMask Stains / Exposure 20 ms

Mitochondria

c15440-20up Application example 3

Mitochondria:
MitoTracker / Exposure 500 ms

Membrane

c15440-20up Application example 2

Membrane:
CellMask Plasma Membrane stains / Exposure 500 ms

PC recommendations

With the introduction of the ORCA-Fusion BT, users are now able to stream 5 megapixel images to their computers 89 frames per second. The computer recommendations for this high data rate can be met by using the guidelines listed this PC Recommendations for ORCA-Fusion BT.

Specifications

Type number C15440-20UP
Quantum efficency @550 nm: 95 %
Imaging device sCMOS
Effective no. of pixels 2304 (H) × 2304 (V)
Cell size 6.5 μm (H) × 6.5 μm (V)
Readout speed Fast scan: 89.1 frames/s (@2304 x 2304 pixels, 16 bit)
Readout noise Ultra-quiet scan: 0.7 electrons rms (Typ.)
Dynamic range 21 400:1 (Typ.)
A/D converter 16 bit, 12 bit, 8 bit

Spectral response

c15440-20up Spectral response

Dimensions

c15440-20up dimensional outline
