Multianode photomultiplier tube
|Type||Metal package type|
|Tube Size||30 x 30 mm|
|Photocathode Area Shape||Multianode|
|Photocathode Area Size||18 x 18 mm|
|Wavelength (Short)||300 nm|
|Wavelength (Long)||850 nm|
|Wavelength (Peak)||400 nm|
|Spectral Response Curve Code||500K|
|Window Material||Borosilicate glass|
|Dynode Structure||Metal channel|
|[Max. Rating] Anode to Cathode Voltage||900 V|
|[Max. Rating] Average Anode Current||0.1 mA|
|Anode to Cathode Supply Voltage||800 V|
|[Cathode] Luminous Sensitivity Min.||150 μA/lm|
|[Cathode] Luminous Sensitivity Typ.||200 μA/lm|
|[Cathode] Red/White Ratio (R-68) Typ.||0.2|
|[Cathode] Radiant Sensitivity Typ.||65 mA/W|
|[Anode] Luminous Sensitivity Min.||50 A/lm|
|[Anode] Luminous Sensitivity Typ.||200 A/lm|
|[Anode] Radiant Sensitivity Typ.||6.5 x 104 A/W|
|[Anode] Gain Typ.||1.0 x 106|
|[Anode] Dark Current (after 30min.) Typ.||2.5/ch nA|
|[Anode] Dark Current (after 30min.) Max.||12.5/ch nA|
|[Time Response] Rise Time Typ.||1.2 ns|
|[Time Response] Transit Time Typ.||9.5 ns|
|[Time Response] Transit Time Spread Typ.||0.36 ns|
|[Anode] Pulse Linearity (2% deviation)||10 mA|
|[Anode] Pulse Linearity (5% deviation)||30 mA|
