Multianode photomultiplier tube
|Type||Metal package type|
|Tube Size||30 x 30 mm|
|Photocathode Area Shape||Square|
|Photocathode Area Size||15.8 x 15.8 mm|
|Wavelength (Short)||300 nm|
|Wavelength (Long)||920 nm|
|Wavelength (Peak)||630 nm|
|Spectral Response Curve Code||-|
|Photocathode Material||Extended red multialkali|
|Window Material||Borosilicate glass|
|Dynode Structure||Metal channel|
|[Max. Rating] Anode to Cathode Voltage||900 V|
|[Max. Rating] Average Anode Current||0.1 mA|
|Anode to Cathode Supply Voltage||800 V|
|[Cathode] Luminous Sensitivity Min.||350 μA/lm|
|[Cathode] Luminous Sensitivity Typ.||500 μA/lm|
|[Cathode] Red/White Ratio (R-68) Typ.||0.45|
|[Cathode] Radiant Sensitivity Typ.||78 mA/W|
|[Anode] Luminous Sensitivity Min.||175 A/lm|
|[Anode] Luminous Sensitivity Typ.||500 A/lm|
|[Anode] Radiant Sensitivity Typ.||7.8 x 104 A/W|
|[Anode] Gain Typ.||1.0 x 106|
|[Anode] Dark Current (after 30min.) Typ.||1/ch nA|
|[Anode] Dark Current (after 30min.) Max.||10/ch nA|
|[Time Response] Rise Time Typ.||0.6 ns|
|[Time Response] Transit Time Typ.||7.4 ns|
