イムノクロマトリーダエンジン
C16171シリーズは、試薬の発色/蛍光ライン検出を行う光学ヘッドと、ヘッドを駆動させるモータおよび制御基板を一体化したエンジンです。C16171-10は吸光法を採用した計測方式で、赤色系試薬の測定に対応したモデルです。
このエンジンを使用することで、高感度なライン検出を実現し、プロファイルデータの取得と波形解析プログラムが活用できます。ライン読み取りに特化した検査装置のコアパーツとして、検査装置の開発に活用いただけます。
項目 | C16171-10 | 単位 |
---|---|---|
対象標識体 | 赤色系試薬 | - |
測定対象*1 | 発色ライン | - |
測定方式 | 吸光測定 | - |
光源 | 緑色LED | - |
*1:同時に2つの測定対象は測定できません。
項目 | C16171-10 | 単位 | ||
---|---|---|---|---|
電源電圧 | 最小値 | +3.0 | V | |
標準値 | +3.3 / +5.0 | V | ||
最大値 | +5.5 | V | ||
電源電流 | パワーダウン時 | 標準値 | 0 | A |
待機時 | 標準値 | 0.05 | A | |
動作時 | 最大値 | 1 | A | |
制御入力電圧 | R x D | 最大値 | +5.5 | V |
PWRDWN | 最大値 | +5.5 | V | |
制御出力電圧 | T x D | 最大値 | +5.5 | V |
動作周囲温度 | +15 ~ +30 | ℃ | ||
動作周囲相対湿度*2 | 80以下 | % RH | ||
保存周囲温度 | -20 ~ +50 | ℃ | ||
保存周囲相対湿度*2 | 80以下 | % RH |
*2:結露なきこと
