広帯域シングルモードパッチコード
aeroGUIDEシリーズ
特長
- シングルモードファイバ
- 1本のファイバで400 nm ～ 2000 nmの導波に対応
- ビーム拡大機構付きの気密封止端面
- 波長に依存しないMFD
- 純石英ファイバ
- PMオプションあり
製品詳細
aeroGUIDEシリーズは、光ビームの伝送およびデリバリ用に設計されたLMA (大モードエリア)ファイバをベースとしています。広帯域シングルモード動作、大モードエリアによる高い耐光性と低非線形性、優れたビーム品質、低損失に加え、偏波保持機能を備えており、従来のファイバでは実現が困難な性能にも対応します。また、ファイバ端面は気密封止およびコネクタ化されており、気密性と堅牢性に優れたインターフェースを備えています。aeroGUIDEシリーズは、シングルモード伝送、多波長伝送、広帯域デリバリ、モードフィルタリング用途に適しています。
用途に応じた2種類のの基本構成
aeroGUIDE シリーズには、2つの基本構成があります。StandardとPowerです。
Standardシリーズは超広帯域の光デリバリ向けに設計されており、Powerシリーズは高出力光のデリバリに最適化されています。
Powerシリーズは、SBS (誘導ブリルアン散乱)により制限を受けやすい、高出力の狭線幅レーザの伝送に特に適しています。
仕様
光学的特性
| aeroGUIDE-5-PM | aeroGUIDE-8 | aeroGUIDE-10-PM | aeroGUIDE-15-PM | aeroGUIDE POWER | |
| 推奨波長 | 400 nm ～ 1500 nm | 400 nm ～ 2000 nm | 450 nm ～ 2000 nm | 500 nm ～ 2000 nm | 500 nm ～ 2000 nm |
| モードフィールド径 @532 nm |
4.8 ± 0.5 μm | 7.2 ± 1.0 μm | 8.4 ± 1.0 μm | 12.2 ± 1.5 μm | 12.2 ± 1.5 μm |
| モードフィールド径 @1064 nm |
– | 12.6 ± 1.5 μm | |||
| シングルモードカットオフ波長 | なし | ||||
| 開口数、1/e² @405 nm | 0.055 ± 0.02 | – | |||
| 開口数、1/e² @532 nm | – | 0.045 ± 0.02 | 0.030 ± 0.02 | – | |
| 開口数、1/e² @808 nm | 0.100 ± 0.02 | – | |||
| 開口数、1/e² @1064 nm | – | 0.085 ± 0.02 | 0.080 ± 0.02 | 0.055 ± 0.02 | – |
| PER @532 nm | > 18 dB | – | > 18 dB | – | |
| 最小曲げ半径 @ 1 μm | – | 20 cm | |||
| 最小曲げ半径 @ 0.5 μm | – | 25 cm | |||
物理的特性
| aeroGUIDE-5-PM | aeroGUIDE-8 | aeroGUIDE-10-PM | aeroGUIDE-15-PM | aeroGUIDE POWER | |
| ファイバ長 (公差: +0.2 / -0)*1 |
2.0 m / 5.0 m | 5.0 m | 5.0 m / 10.0 m | 2.0 m / 5.0 m / 10.0 m | 2.0 m / 3.0 m / 5.0 m / 10.0 m |
| 終端仕様 | FC/APC | SMA-905 | |||
| 端面角度 | 8.0 ° ± 0.5 ° | 5 ° ± 1 ° | |||
| チューブ | 3 mmケブラー補強ファーケーションチューブ | スクエアロックスチール | |||
| ファイバコアおよびクラッド材料 | 石英 | ||||
*1 表記値は最短保証長です。
