|PMT管径||38 (1-1/2) mm|
|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[絶対最大定格] 陽極－陰極間電圧||-1500 V|
|[絶対最大定格] デバイダ電流||0.39 mA|
|陽極－陰極間 印加電圧||-1300 V|
|[陰極特性] ルーメン感度 Min.||70 μA/lm|
|[陰極特性] ルーメン感度 Typ.||95 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||11|
|[陰極特性] 放射感度 Typ.||88 mA/W|
|[陽極特性] ルーメン感度 Min.||5 A/lm|
|[陽極特性] ルーメン感度 Typ.||47 A/lm|
|[陽極特性] 放射感度 Typ.||4.4 x 104 A/W|
|[陽極特性] ゲイン Typ.||5.0 x 105|
|[陽極特性] 暗電流(30分後) Typ.||10 nA|
|[陽極特性] 暗電流(30分後) Max.||100 nA|
|[時間特性] 上昇時間 (Tr) Typ.||1.6 ns|
|[時間特性] 走行時間 (T.T.) Typ.||17 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||0.55 ns|
|[陽極特性] パルスリニアリティ （2%変動）||30 mA|
|[陽極特性] パルスリニアリティ （5%変動）||50 mA|
