|感度波長 (Short)||160 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||400 nm|
|[最大定格] 陽極－陰極間電圧||-3400 V|
|[最大定格] 平均陽極電流||0.0001 mA|
|陽極－陰極間 印加電圧||-3000 V|
|[陰極特性] ルーメン感度 Min.||20 μA/lm|
|[陰極特性] ルーメン感度 Typ.||45 μA/lm|
|[陰極特性] 放射感度 Typ.||48 mA/W|
|[陽極特性] ルーメン感度 Typ.||9 A/lm|
|[陽極特性] ゲイン Typ.||2.0 x 105|
|[陽極特性] 暗電流(30分後) Max.||0.5 nA|
|[時間特性] 上昇時間 (Tr) Typ.||0.18 ns|
|[時間特性] 走行時間 (T.T.) Typ.||1 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||0.09 ns|
