LIGHTNINGCURE LC-L1V5
L14310 / L14311 / C14052シリーズ
4ヘッド独立駆動のスポット照射型UV-LED光源です。
手のひらサイズのコンパクト設計により、僅かなスペースへの設置など自由自在な設計を可能にします。弊社独自のフィードバック機能により、点灯直後から常に光出力変動 ±5 %以下となっています。
仕様
LEDヘッドユニット L14310シリーズ
| 項目 | 標準型 | 単位 | |||||
|---|---|---|---|---|---|---|---|
| 照射エリア φ3 mmタイプ |
照射エリア φ6 mmタイプ |
照射エリア φ8 mmタイプ |
照射エリア φ12 mmタイプ |
||||
| L14310-□10 (*1) (*2) |
L14310-□15 (*1) (*2) |
L14310-□20 (*1) (*2) |
L14310-□00 (*1) (*2) |
||||
| 装着集光レンズ | E11923-010 | E11923-015 | E11923-020 | — | — | ||
| 焦点距離 | 10 | 15 | 20 | 10 | mm | ||
| 照射エリア (*3) | 約φ3 | 約φ6 | 約φ8 | 約φ10 | mm | ||
| 波長 | 365 / 385 / 405 | nm | |||||
| 紫外線照射強度 (*4) | 14000 | 6500 | 4000 | 1000 | mW/cm2 | ||
| LED設計寿命 (*5) | 20000 | h | |||||
| 冷却方式 | 自然空冷 | － | |||||
| 動作温度範囲 | +5 ℃ ～ +40 ℃ | － | |||||
| 保存温度範囲 | -10 ℃ ～ +60 ℃（氷結なきこと） | － | |||||
| 動作湿度範囲 | 20 % ～ 80 %（結露なきこと） | － | |||||
| 保存湿度範囲 | 80 %以下（結露なきこと） | － | |||||
| 適合規格 | EMC規格 | IEC 61326-1 Emission limits: CISPR 11 Group 1 Class A Immunity requirements: Table 2 |
— | ||||
| 安全性規格 | IEC/EN 61010-1/A1 | ||||||
*1: L14310-□00 + 集光レンズ E11923シリーズのセット型名です。
集光レンズ E11923シリーズを取り替えることで焦点距離・照射エリアを変えることが可能です。
*2: 型名の「□」の部分は波長別のサフィックスとなります。 1: 365 nm / 2: 385 nm / 3: 405 nm
*3: 焦点距離で測定した際の照射エリアです。
*4: 焦点距離で測定した際の照射エリア内での最大紫外線照射強度です。
*5: 動作温度25 ℃にて、紫外線照射強度が初期値の70 %になるまでの平均時間です。
LEDヘッドユニット L14311シリーズ
| 項目 | 直角照射型 | リニアビーム型 | 単位 | ||||
|---|---|---|---|---|---|---|---|
| 中焦点タイプ | 長焦点タイプ | 広範囲照射タイプ | 部分照射タイプ | ||||
| L14311-□03 (*2) | L14311-□05 (*2) | L14311-□02 (*2) | L14311-□04 (*2) | ||||
| 装着集光レンズ | — | — | — | — | — | ||
| 焦点距離 | 10 | 20 | 15 | 10 | mm | ||
| 照射エリア (*3) | 約φ6 | 約φ7 | 約φ20 x 6 | 約φ12 x 4 | mm | ||
| 波長 | 365 / 385 / 405 | nm | |||||
| 紫外線照射強度 (*4) | 4000 | 3000 | 1200 | 3000 | mW/cm2 | ||
| LED設計寿命 (*5) | 20000 | h | |||||
| 冷却方式 | 自然空冷 | － | |||||
| 動作温度範囲 | +5 ℃ ～ +40 ℃ | － | |||||
| 保存温度範囲 | -10 ℃ ～ +60 ℃（氷結なきこと） | － | |||||
| 動作湿度範囲 | 20 % ～ 80 %（結露なきこと） | － | |||||
| 保存湿度範囲 | 80 %以下（結露なきこと） | － | |||||
| 適合規格 | EMC規格 | IEC 61326-1 Emission limits: CISPR 11 Group 1 Class A Immunity requirements: Table 2 |
— | ||||
| 安全性規格 | IEC/EN 61010-1/A1 | ||||||
*2: 型名の「□」の部分は波長別のサフィックスとなります。 1: 365 nm / 2: 385 nm / 3: 405 nm
*3: 焦点距離で測定した際の照射エリアです。
*4: 焦点距離で測定した際の照射エリア内での最大紫外線照射強度です。
*5: 動作温度25 ℃にて、紫外線照射強度が初期値の70 %になるまでの平均時間です。
集光レンズ E11923シリーズ
| 項目 | E11923-010 | E11923-015 | E11923-020 | 単位 | ||
|---|---|---|---|---|---|---|
| 焦点距離 | 10 | 15 | 20 | mm | ||
| 照射エリア (*6) | 約φ3 | 約φ6 | 約φ8 | mm | ||
| 動作温度範囲 | +5 ℃ ～ +40 ℃ | － | ||||
| 保存温度範囲 | -10 ℃ ～ +60 ℃（氷結なきこと） | － | ||||
| 動作湿度範囲 | 20 % ～ 80 %（結露なきこと） | － | ||||
| 保存湿度範囲 | 80 %以下（結露なきこと） | － | ||||
*6: 焦点距離で測定した際の照射エリアです。
コントローラ C14052シリーズ
| 項目 | C14052-0-□□ (*7) | C14052-1-□□ (*7) | C14052-2-□□ (*7) | 単位 | ||
|---|---|---|---|---|---|---|
| 入力電圧（AC） | 100 V ～ 240 V、単相 50 Hz / 60 Hz (*8) | — | ||||
| 消費電力 (*9) | Max. | 25 | W | |||
| 冷却方式 | 自然空冷 | — | ||||
| 動作温度範囲 | +5 ℃ ～ +40 ℃ | － | ||||
| 保存温度範囲 | -10 ℃ ～ +60 ℃（氷結なきこと） | － | ||||
| 動作湿度範囲 | 20 % ～ 80 %（結露なきこと） | － | ||||
| 保存湿度範囲 | 80 %以下（結露なきこと） | － | ||||
| 外部制御 | 点灯制御、点灯信号、各種エラー信号 | — | ||||
| 通信制御 | 通信制御なし | USB通信制御 | RS-232C通信制御 | — | ||
| — | 点灯制御、点灯信号、点灯時間の積算・表示・リセット オート照射 プログラム設定、各種エラー信号 |
|||||
| 適合規格 | EMC規格 | IEC 61326-1 Emission limits: CISPR 11 Group 1 Class A Immunity requirements: Table 2 |
— | |||
| 安全性規格 | IEC/EN 61010-1/A1 | |||||
*7: 型名の「□」の部分はACアダプタの仕様別のサフィックスとなります。
○ACアダプタ無し 記載無し：お客様にて直流 12 V、24 W以上の出力のACアダプタをご用意ください。また、お客様にてEMC試験および安全性試験を行ってください。
○ACアダプタ有り A1：日本向け／A2：米国向け／A3：欧州向け／A4：中国向け／A5：英国向け／A7：タイ向け
C14052-0の場合は「-0」が省略されるため、型名は「C14052」となります。
*8: コントローラへの入力電圧はDC 12 V ±0.5 Vです。
*9: 4ヘッド駆動の際の値です。
特性
照射強度分布（代表値：365 nm）
標準型：照射エリア φ3 mmタイプ
標準型：照射エリア 約φ6 mmタイプ
標準型：照射エリア φ8 mmタイプ
標準型：照射エリア φ12 mmタイプ
NOTE：LEDヘッドユニットの外形寸法の中心と照射光の中心が一致しない場合があります。必要に応じて、設置位置を調整してください。
照射形状は照射距離に応じて変化します。照射距離によっては四角形に近い形となります。
LED素子の発光強度のバラつきにより、LEDヘッドユニットには個体差があります。
