C7557-01は、マルチチャンネル測光の基本操作用として開発されたコントローラです。当社製マルチチャンネル検出器ヘッドとパソコンに接続し、付属のソフトウェアを使用することによって、容易に検出器ヘッドの制御とデータ収集を行うことができます。C7557-01は、CCD/NMOS/InGaAsイメージセンサに対応する、主なマルチチャンネル検出器ヘッドをサポートしています。各種機能を備えているため、効率的にデータを収集することが可能です。コントローラ本体には、マルチチャンネル検出器ヘッドをコントロールするためのドライバ回路、電源回路、温度安定回路、検出器ヘッドからのアナログ出力信号をデジタル信号に変換するためのA/D変換回路とデータインターフェースが内蔵されています。付属のソフトウェアを使用することによって、USBインターフェースを通して簡易に制御およびデータ収集を行います。ソフトウェアはMicrosoft® Windows®に対応しており、画面上に整理されたメニューから、容易に操作を行うことができます。また、このソフトウェアには各種のDLL が用意されています。DLLを使用することにより、ソフトウェア開発を行うことができます。■特長
